Locking mechanism
Pair of safety locks for Renault Master, Opel Movano, Nissan NV 400 2010+ and Iveco Daily 2014+ cabs
HEO15146
€135.00
Tax included
2-5 working days
Locking mechanism
check_circle
En stock magasin ou fournisseur
This product is compatible?
Check compatibility
Door frame assembly
1 pair of locks (1 x left / 1 x right) + Additional part (bolt stop column B)
Locking bolt
OPERATING INSTRUCTIONS :
- Pressing the knob closes or opens the door.
- The turning knob locks automatically as soon as the deadbolt is completely unscrewed or screwed in.
INSTALLATION INSTRUCTIONS :
- Position the lock on the door frame. The distance between the lock box and column B should be approx. 3 mm.
- At the height of the bolt, push the rubber gasket between column B and the cabin lining.
- Position the lock so that the closed bolt pushes against the lining.
- Now you can mark the holes.
- Remove the lock and drill a pilot hole using a 3.2 mm bit.
- Secure the special tapping screws with a 4 mm Allen® key.
IMPORTANT ASSEMBLY INSTRUCTIONS :
After installation, close the door gently and make sure that the HEOSafe® lock box passes through the rubber seal without any problems.
For further information, please do not hesitate to contact us:
- Position the lock on the door frame. The distance between the lock box and column B should be approx. 3 mm.
- At the height of the bolt, push the rubber gasket between column B and the cabin lining.
- Position the lock so that the closed bolt pushes against the lining.
- Now you can mark the holes.
- Remove the lock and drill a pilot hole using a 3.2 mm bit.
- Secure the special tapping screws with a 4 mm Allen® key.
IMPORTANT ASSEMBLY INSTRUCTIONS :
After installation, close the door gently and make sure that the HEOSafe® lock box passes through the rubber seal without any problems.
For further information, please do not hesitate to contact us:
